Martin 82A9 MAR82A9
Martin Accu-Torch® 82A9 Type A Reboreable Flame Cut Sprocket, 1.25 to 7.073 in Dia Bore, 9.449 in OD, #82 Chain, 9 Teeth, 3.075 in Pitch, 8.991 in Dia Pitch, Steel
- Manufacturer: Martin Sprocket & Gear
- Brand Name: Martin
- Part Number: MAR82A9
- MPN: 82A9
- UPC: 697950067896
- Min. Order Qty: 1
- Qty. Interval: 1
- Sign In for Pricing and Availability
- Sold As: 1/EA
-
Price:
Martin Accu-Torch® steel sprockets are available for virtually all engineering class chains in style A, B, and C. Also available as split with welded hub and split or solid detachable hub. They can also be furnished as shear pin type. Where possible please specify chain number, pitch diameter, number of teeth, bore and keyway size, and hub style required. Accu-Torch® sprockets are not intended to replace cut tooth roller chain sprockets.
Martin Accu-Torch® Flame Cut Sprocket, Type A Reboreable, 1.25 to 7.073 in Bore, 9.449 in OD, #82 Chain, 9 Teeth, 3.075 in Pitch, 8.991 in Pitch Diameter, 1.102 in Length Through Bore, Steel
| Bore Diameter | : | 1.25 to 7.073 in |
| Chain Size | : | #82 |
| Length Through Bore | : | 1.102 in |
| Material | : | Steel |
| Number of Teeth | : | 9 |
| Outside Diameter | : | 9.449 in |
| Pitch Diameter | : | 8.991 in |
| Pitch | : | 3.075 in |
| Type | : | Type A Reboreable |
- Item Features 01=Manufactured of high carbon steel
- Item Features 02=Precise machining and processes ensure consistent finish and high quality
