Martin 80BTB27H MAR80BTB27H
Martin Saber Tooth® 80BTB27H Taper Bushed Type B Single Pitch Roller Chain Sprocket With Hardened Teeth, 9.156 in OD, #80 Chain, 27 Teeth, 1 in Pitch, Steel
- Manufacturer: Martin Sprocket & Gear
- Brand Name: Martin
- Part Number: MAR80BTB27H
- MPN: 80BTB27H
- UPC: 697950065670
- Min. Order Qty: 1
- Qty. Interval: 1
- Sign In for Pricing and Availability
- Sold As: 1/EA
-
Price:
A hardened taper bushed sprocket is a sprocket where a tapered bushing is bolted into the taper bore that is machined in the sprocket. When installed this bushing is compressed onto the shaft providing a tight grip. Taper bushed sprockets have a tapered bushing bolted into a taper bore with hex head set screws instead of bolts.
Martin Saber Tooth® Single Pitch Roller Chain Sprocket, Taper Bushed Type B, 9.156 in Outside Dia, #80 Chain, 27 Teeth, 1 in Pitch, 8.614 in, 4-1/4 in Hub Dia, 1-3/4 in Length Through Bore, 2517 Taper Lock Bushing, Steel
| Bushing Type | : | 2517 Taper Lock |
| Chain Size | : | #80 |
| Hub Diameter | : | 4-1/4 in |
| Length Through Bore | : | 1-3/4 in |
| Material | : | Steel |
| Number of Teeth | : | 27 |
| Outside Diameter | : | 9.156 in |
| Pitch Diameter | : | 8.614 in |
| Pitch | : | 1 in |
| Type | : | Taper Bushed Type B |
- Manufactured of high carbon steel
- Precise machining and processes ensure consistent finish and high quality
- Chain rows are parallel and precisely spaced to increase longevity of sprocket and chain
