Martin 50Q44 MAR50Q44
  1. pin-int

Martin 50Q44 MAR50Q44

Martin 50Q44 MST® Q1 Bushed Type 4 Welded Split Single Roller Chain Sprocket, 0.75 to 2.688 in Dia Bore, 9.114 in OD, 50 Chain, 44 Teeth, 5/8 in Pitch, Steel

  • Manufacturer: Martin Sprocket & Gear
  • Brand Name: Martin
  • Part Number: MAR50Q44
  • MPN: 50Q44
  • UPC: 697950137995
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • loading
  • Sign In for Pricing and Availability

Martin split taper sprocket is another style of bushed sprocket. The split taper bushing, when installed, offers a wide range of bore sizes.

Martin Split Single Roller Chain Sprocket, MST® Q1 Bushed Type 4 Welded, 0.75 to 2.688 in Bore Dia, 9.114 in Outside Dia, 50 Chain, 44 Teeth, 5/8 in Pitch, 8.761 in, 4-1/4 in Hub Dia, 1/2 in W Keyway, 2-1/2 in Length Through Bore, Type Q1 Split Taper Bushing, Steel

Bore Diameter      :      0.75 to 2.688 in
Bushing Type      :      Type Q1 Split Taper
Chain Size      :      50
Hub Diameter      :      4-1/4 in
Keyway Size      :      1/2 in W
Length Through Bore      :      2-1/2 in
Material      :      Steel
Number of Teeth      :      44
Outside Diameter      :      9.114 in
Pitch Diameter      :      8.761 in
Pitch      :      5/8 in
Type      :      MST® Q1 Bushed Type 4 Welded
  • Manufactured of high carbon steel
  • Precise machining and processes ensure consistent finish and high quality
  • Chain rows are parallel and precisely spaced to increase longevity of sprocket and chain
