Martin 41BS96 1 7/16 MAR41BS961 7/16
  1. pin-int

Martin 41BS96 1 7/16 MAR41BS961 7/16

Martin 41BS96 1 7/16 Type B Bored-to-Size Single Strand Welded Roller Chain Sprocket, 1-7/16 in Dia Bore, 15.573 in OD, #41 Chain, 96 Teeth, 1/2 in Pitch, Steel

  • Manufacturer: Martin Sprocket & Gear
  • Brand Name: Martin
  • Part Number: MAR41BS961 7/16
  • MPN: 41BS96 1 7/16
  • UPC: 697950300627
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • loading
  • Sign In for Pricing and Availability

These finished bore sprockets are shaft ready and come complete with keyways and setscrews. The keyways are on center line of the tooth. Bored to size sprockets with 1/2 in bores and smaller are stocked with (2) setscrews only.

Martin Roller Chain Sprocket, Type B Bored-to-Size Single Strand Welded, 1-7/16 in Bore, 15.573 in OD, #41 Chain, 96 Teeth, 1/2 in Pitch, 15.2816 in Pitch Diameter, 4 in Diameter Hub, 3/8-16 x 3/8 in Screw, 3/8 x 3/16 in Keyway, 1.188 in Length Through Bore, Steel

Bore Diameter      :      1-7/16 in
Chain Size      :      #41
Hub Diameter      :      4 in
Keyway Size      :      3/8 x 3/16 in
Length Through Bore      :      1.188 in
Material      :      Steel
Number of Teeth      :      96
Outside Diameter      :      15.573 in
Pitch Diameter      :      15.2816 in
Pitch      :      1/2 in
Screw Size      :      3/8-16 x 3/8 in
Type      :      Type B Bored-to-Size Single Strand Welded
  • Precise machining and processes ensure consistent finish and high quality
  • Bores are concentric to pitch line, minimizing run out
  • 2 set screws keyed on centerline of tooth
