Martin 41B24 MAR41B24

Martin 41B24 Type B Single Strand Solid Stock Bore Roller Chain Sprocket, 5/8 to 2-1/4 in Dia Bore, 4.098 in OD, #41 Chain, 24 Teeth, 1/2 in Pitch, Steel

  • Manufacturer: Martin Sprocket & Gear
  • Brand Name: Martin
  • Part Number: MAR41B24
  • MPN: 41B24
  • UPC: 697950009148
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • loading
  • Sign In for Pricing and Availability

B style sprockets are flat sprockets with a hub extension on one side. These plain bore sprockets can easily be bored to a metric or standard size to fit your application. Keyways, set screws and harden teeth are quick alterations that can be made.

Martin Roller Chain Sprocket, Type B Single Strand Solid Stock Bore, 5/8 to 2-1/4 in Bore, 4.098 in OD, #41 Chain, 24 Teeth, 1/2 in Pitch, 3.831 in Pitch Diameter, 3-1/4 in Diameter Hub, 1 in Length Through Bore, Steel

Bore Diameter      :      5/8 to 2-1/4 in
Chain Size      :      #41
Hub Diameter      :      3-1/4 in
Length Through Bore      :      1 in
Material      :      Steel
Number of Teeth      :      24
Outside Diameter      :      4.098 in
Pitch Diameter      :      3.831 in
Pitch      :      1/2 in
Type      :      Type B Single Strand Solid Stock Bore
  • Without hardened teeth
  • Manufactured of high carbon steel
  • Precise machining and processes ensure consistent finish and high quality
  • pdfSpecification Sheet https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Martin_D06B114_Specification_Sheet.pdf
