Martin 40SH26H MAR40SH26H
  1. pin-int

Martin 40SH26H MAR40SH26H

Martin 40SH26H Type B Single Strand Solid Bushed Roller Chain Sprocket With Hardened Teeth, 0.5 to 1.688 in Dia Bore, 4.418 in OD, #40 Chain, 26 Teeth, 1/2 in Pitch, Steel

  • Manufacturer: Martin Sprocket & Gear
  • Brand Name: Martin
  • Part Number: MAR40SH26H
  • MPN: 40SH26H
  • UPC: 697950041698
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • loading
  • Sign In for Pricing and Availability

Martin saber tooth sprockets have hardened teeth, which provide longer chain and sprocket life. The hardened teeth on the smaller sprocket of a roller chain drive are recommended if the drive ratio is four to one or greater if the smaller sprocket has 24 teeth or less and is running at a speed of over 600 rpm.

Martin Roller Chain Sprocket, Type B Single Strand Solid Bushed, 0.5 to 1.688 in Bore, 4.418 in OD, #40 Chain, 26 Teeth, 1/2 in Pitch, 4.1481 in Pitch Diameter, 3 in Diameter Hub, 1/4-20 UNC Screw, 13/16 in Length Through Bore, QD® SH Bushing, Steel

Bore Diameter      :      0.5 to 1.688 in
Bushing Type      :      QD® SH
Chain Size      :      #40
Hub Diameter      :      3 in
Length Through Bore      :      13/16 in
Material      :      Steel
Number of Teeth      :      26
Outside Diameter      :      4.418 in
Pitch Diameter      :      4.1481 in
Pitch      :      1/2 in
Screw Size      :      1/4-20 UNC
Type      :      Type B Single Strand Solid Bushed
  • Item Features 01=Interchangeable with other manufacturer's QD® bushings
  • Item Features 02=Stocked heat treat
  • Item Features 03=Precise machining and processes ensure consistent finish and high quality
  • Item Features 04=Chain rows are parallel and precisely spaced to increase longevity of sprocket and chain
  • Item Features 05=Bores are concentric to pitch line, minimizing run out
