Martin 40C17 MAR40C17
  1. pin-int

Martin 40C17 MAR40C17

Martin 40C17 Type C Single Strand Welded Reboreable Roller Chain Sprocket, 5/8 to 1-7/16 in Dia Bore, 2.975 in OD, #40 Chain, 17 Teeth, 1/2 in Pitch, Steel

  • Manufacturer: Martin Sprocket & Gear
  • Brand Name: Martin
  • Part Number: MAR40C17
  • MPN: 40C17
  • UPC: 697950183718
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • loading
  • Sign In for Pricing and Availability

C Style sprockets are flat sprockets with a hub extension on either side. These plain bore sprockets can easily be bored to a metric or standard size to fit your application. Keyways, setscrews and hardened teeth are quick alterations that can be made.

Martin Roller Chain Sprocket, Type C Single Strand Welded Reboreable, 5/8 to 1-7/16 in Bore, 2.975 in OD, #40 Chain, 17 Teeth, 1/2 in Pitch, 2.7211 in Pitch Diameter, 2-1/8 in Diameter Hub, 1-1/2 in Length Through Bore, Steel

Bore Diameter      :      5/8 to 1-7/16 in
Chain Size      :      #40
Hub Diameter      :      2-1/8 in
Length Through Bore      :      1-1/2 in
Material      :      Steel
Number of Teeth      :      17
Outside Diameter      :      2.975 in
Pitch Diameter      :      2.7211 in
Pitch      :      1/2 in
Type      :      Type C Single Strand Welded Reboreable
  • Item Features 01=Manufactured of high carbon steel
  • Item Features 02=Precise machining and processes ensure consistent finish and high quality
  • Item Features 03=Bores are concentric to pitch line, minimizing run out
