Martin 40BS37 3/4 MAR40BS373/4

Martin 40BS37 3/4 Type B Bored-to-Size Single Strand Welded Roller Chain Sprocket, 3/4 in Dia Bore, 6.175 in OD, #40 Chain, 37 Teeth, 1/2 in Pitch, Steel

  • Manufacturer: Martin Sprocket & Gear
  • Brand Name: Martin
  • Part Number: MAR40BS373/4
  • MPN: 40BS37 3/4
  • UPC: 697950301020
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • loading
  • Sign In for Pricing and Availability

These finished bore sprockets are shaft ready and come complete with keyways and setscrews. The keyways are on center line of the tooth. Bored to size sprockets with 1/2 in bores and smaller are stocked with (2) setscrews only.

Martin Roller Chain Sprocket, Type B Bored-to-Size Single Strand Welded, 3/4 in Bore, 6.175 in OD, #40 Chain, 37 Teeth, 1/2 in Pitch, 5.8958 in Pitch Diameter, 3-1/4 in Diameter Hub, 1/4-20 x 1/4 in Screw, 3/16 x 3/32 in Keyway, 1 in Length Through Bore, Steel

Bore Diameter      :      3/4 in
Chain Size      :      #40
Hub Diameter      :      3-1/4 in
Keyway Size      :      3/16 x 3/32 in
Length Through Bore      :      1 in
Material      :      Steel
Number of Teeth      :      37
Outside Diameter      :      6.175 in
Pitch Diameter      :      5.8958 in
Pitch      :      1/2 in
Screw Size      :      1/4-20 x 1/4 in
Type      :      Type B Bored-to-Size Single Strand Welded
  • Item Features 01=Precise machining and processes ensure consistent finish and high quality
  • Item Features 02=Bores are concentric to pitch line, minimizing run out
  • Item Features 03=2 set screws keyed on centerline of tooth
