Martin 35JA25 MAR35JA25

Martin 35JA25 Type B Single Strand Solid Stock Bore Roller Chain Sprocket, 1-1/4 in Dia Bore, 3.193 in OD, #35 Chain, 25 Teeth, 3/8 in Pitch, Steel

  • Manufacturer: Martin Sprocket & Gear
  • Brand Name: Martin
  • Part Number: MAR35JA25
  • MPN: 35JA25
  • UPC: 697950001951
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • loading
  • Sign In for Pricing and Availability

QD® (Quick Detachable) is a sprocket where a tapered bushing is bolted into the taper bore that is machined in the sprocket. When installed this bushing is compressed onto the shaft providing a tight grip.

Martin Roller Chain Sprocket, Type B Single Strand Solid Stock Bore, 1-1/4 in Bore, 3.193 in OD, #35 Chain, 25 Teeth, 3/8 in Pitch, 2.992 in Pitch Diameter, 2 in Diameter Hub, 1-1/4 in Length Through Bore, QD® JA Bushing, Steel

Bore Diameter      :      1-1/4 in
Bushing Type      :      QD® JA
Chain Size      :      #35
Hub Diameter      :      2 in
Length Through Bore      :      1-1/4 in
Material      :      Steel
Number of Teeth      :      25
Outside Diameter      :      3.193 in
Pitch Diameter      :      2.992 in
Pitch      :      3/8 in
Type      :      Type B Single Strand Solid Stock Bore
  • Item Features 01=Without hardened teeth
  • Item Features 02=Manufactured of high carbon steel
  • Item Features 03=Precise machining and processes ensure consistent finish and high quality
  • Item Features 04=Chain rows are parallel and precisely spaced to increase longevity of sprocket and chain
  • pdfSpecification Sheet https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Martin_D06B114_Specification_Sheet.pdf
