Martin 35H22 MAR35H22
  1. pin-int

Martin 35H22 MAR35H22

Martin 35H22 MST® H Bushed Solid Type 3 Split Single Roller Chain Sprocket With Recess Groove, 3/8 to 1-1/2 in Dia Bore, 2.833 in OD, 35 Chain, 22 Teeth, 3/8 in Pitch, Steel

  • Manufacturer: Martin Sprocket & Gear
  • Brand Name: Martin
  • Part Number: MAR35H22
  • MPN: 35H22
  • UPC: 697950097312
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • loading
  • Sign In for Pricing and Availability

Martin split taper sprocket is another style of bushed sprocket. The split taper bushing, when installed, offers a wide range of bore sizes.

Martin Split Single Roller Chain Sprocket, MST® H Bushed Solid Type 3, 3/8 to 1-1/2 in Bore Dia, 2.833 in Outside Dia, 35 Chain, 22 Teeth, 3/8 in Pitch, 2.635 in, 2.51 in Hub Dia, 1-1/4 in Length Through Bore, Type H Split Taper Bushing, Steel

Bore Diameter      :      3/8 to 1-1/2 in
Bushing Type      :      Type H Split Taper
Chain Size      :      35
Hub Diameter      :      2.51 in
Length Through Bore      :      1-1/4 in
Material      :      Steel
Number of Teeth      :      22
Outside Diameter      :      2.833 in
Pitch Diameter      :      2.635 in
Pitch      :      3/8 in
Type      :      MST® H Bushed Solid Type 3
  • Manufactured of high carbon steel
  • Precise machining and processes ensure consistent finish and high quality
  • Chain rows are parallel and precisely spaced to increase longevity of sprocket and chain
