Martin 35BTB23 MAR35BTB23
  1. pin-int

Martin 35BTB23 MAR35BTB23

Martin 35BTB23 Type B Single Strand Solid Bushed Roller Chain Sprocket, 1/2 to 1-1/4 in Dia Bore, 2.953 in OD, #35 Chain, 23 Teeth, 3/8 in Pitch, Steel

  • Manufacturer: Martin Sprocket & Gear
  • Brand Name: Martin
  • Part Number: MAR35BTB23
  • MPN: 35BTB23
  • UPC: 697950060385
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • loading
  • Sign In for Pricing and Availability

A taper bushed sprocket is a sprocket where a tapered bushing is bolted into the taper bore that is machined in the sprocket. When installed this bushing is compressed onto the shaft providing a tight grip. Taper bushed sprockets have a tapered bushing bolted into a taper bore with hex head setscrews instead of bolts.

Martin Roller Chain Sprocket, Type B Single Strand Solid Bushed, 1/2 to 1-1/4 in Bore, 2.953 in OD, #35 Chain, 23 Teeth, 3/8 in Pitch, 2.754 in Pitch Diameter, 2-3/8 in Diameter Hub, 1 in Length Through Bore, TB 1210 Bushing, Steel

Bore Diameter      :      1/2 to 1-1/4 in
Bushing Type      :      TB 1210
Chain Size      :      #35
Hub Diameter      :      2-3/8 in
Length Through Bore      :      1 in
Material      :      Steel
Number of Teeth      :      23
Outside Diameter      :      2.953 in
Pitch Diameter      :      2.754 in
Pitch      :      3/8 in
Type      :      Type B Single Strand Solid Bushed
  • Interchangeable with other manufacturer's taper bushings
  • Precise machining and processes ensure consistent finish and high quality
  • Chain rows are parallel and precisely spaced to increase longevity of sprocket and chain
  • Bores are concentric to pitch line, minimizing run out
