Martin 35A45SS MAR35A45SS
  1. pin-int

Martin 35A45SS MAR35A45SS

Martin 35A45SS Type A Single Strand Solid Reboreable Roller Chain Sprocket, 19/32 to 19/32 in Dia Bore, 5.588 in OD, #35 Chain, 45 Teeth, 3/8 in Pitch, 303/304 Stainless Steel

  • Manufacturer: Martin Sprocket & Gear
  • Brand Name: Martin
  • Part Number: MAR35A45SS
  • MPN: 35A45SS
  • UPC: 697950064987
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • loading
  • Sign In for Pricing and Availability

Stainless steel sprockets are stocked as plates with no hubs and as "B"s with a hub on one side. They are all ready to be bored or modified to fit specific applications.

Martin Roller Chain Sprocket, Type A Single Strand Solid Reboreable, 19/32 to 19/32 in Bore, 5.588 in OD, #35 Chain, 45 Teeth, 3/8 in Pitch, 5.376 in Pitch Diameter, 0.168 in Length Through Bore, 303/304 Stainless Steel

Bore Diameter      :      19/32 to 19/32 in
Chain Size      :      #35
Length Through Bore      :      0.168 in
Material      :      303/304 Stainless Steel
Number of Teeth      :      45
Outside Diameter      :      5.588 in
Pitch Diameter      :      5.376 in
Pitch      :      3/8 in
Type      :      Type A Single Strand Solid Reboreable
  • Precise machining and processes ensure consistent finish and high quality
  • Bores are concentric to pitch line, minimizing run out
