Martin 35A23 MAR35A23

Martin 35A23 Type A Single Strand Solid Reboreable Roller Chain Sprocket, 0.5 to 2.323 in Dia Bore, 2.953 in OD, #35 Chain, 23 Teeth, 3/8 in Pitch, Steel

  • Manufacturer: Martin Sprocket & Gear
  • Brand Name: Martin
  • Part Number: MAR35A23
  • MPN: 35A23
  • UPC: 697950001814
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • loading
  • Sign In for Pricing and Availability

A Plates are flat sprockets with no hub extension on either side. They can be altered for your application with bolt holes, custom bores, hardened teeth or special hubs welded to them.

Martin Roller Chain Sprocket, Type A Single Strand Solid Reboreable, 0.5 to 2.323 in Bore, 2.953 in OD, #35 Chain, 23 Teeth, 3/8 in Pitch, 2.754 in Pitch Diameter, 0.168 in Length Through Bore, Steel

Bore Diameter      :      0.5 to 2.323 in
Chain Size      :      #35
Length Through Bore      :      0.168 in
Material      :      Steel
Number of Teeth      :      23
Outside Diameter      :      2.953 in
Pitch Diameter      :      2.754 in
Pitch      :      3/8 in
Type      :      Type A Single Strand Solid Reboreable
  • Item Features 01=Precise machining and processes ensure consistent finish and high quality
