Martin 25A28 MAR25A28
  1. pin-int

Martin 25A28 MAR25A28

Martin 25A28 Type A Single Strand Solid Reboreable Roller Chain Sprocket, 0.375 to 1.939 in Dia Bore, 2.369 in OD, #25 Chain, 28 Teeth, 1/4 in Pitch, Steel

  • Manufacturer: Martin Sprocket & Gear
  • Brand Name: Martin
  • Part Number: MAR25A28
  • MPN: 25A28
  • UPC: 697950000114
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • loading
  • Sign In for Pricing and Availability

A Plates are flat sprockets with no hub extension on either side. They can be altered for your application with bolt holes, custom bores, hardened teeth or special hubs welded to them.

Martin Roller Chain Sprocket, Type A Single Strand Solid Reboreable, 0.375 to 1.939 in Bore, 2.369 in OD, #25 Chain, 28 Teeth, 1/4 in Pitch, 2.2329 in Pitch Diameter, 0.11 in Length Through Bore, Steel

Bore Diameter      :      0.375 to 1.939 in
Chain Size      :      #25
Length Through Bore      :      0.11 in
Material      :      Steel
Number of Teeth      :      28
Outside Diameter      :      2.369 in
Pitch Diameter      :      2.2329 in
Pitch      :      1/4 in
Type      :      Type A Single Strand Solid Reboreable
  • Precise machining and processes ensure consistent finish and high quality
  • pdfSpecification Sheet https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Martin_815A13B_Specification_Sheet.pdf
