Martin 24A60 MAR24A60
Martin 24A60 Type A Single Strand Solid Stock Bore Roller Chain Sprocket, 40 mm Dia Bore, 749.808 mm OD, #24B-1 Chain, 60 Teeth, 38.1 mm Pitch, Steel
- Manufacturer: Martin Sprocket & Gear
- Brand Name: Martin
- Part Number: MAR24A60
- MPN: 24A60
- UPC: 697950406152
- Min. Order Qty: 1
- Qty. Interval: 1
- Sign In for Pricing and Availability
- Sold As: 1/EA
-
Price:
Metric A plates are flat sprockets with no hub extension on either side. They can be altered for your application with bolt holes, custom bores, hardened teeth or special hubs welded to them.
Martin Roller Chain Sprocket, Type A Single Strand Solid Stock Bore, 40 mm Bore, 749.808 mm OD, #24B-1 Chain, 60 Teeth, 38.1 mm Pitch, 727.99 mm Pitch Diameter, 102 mm Length Through Bore, Steel
| Bore Diameter | : | 40 mm |
| Chain Size | : | #24B-1 |
| Length Through Bore | : | 102 mm |
| Material | : | Steel |
| Number of Teeth | : | 60 |
| Outside Diameter | : | 749.808 mm |
| Pitch Diameter | : | 727.99 mm |
| Pitch | : | 38.1 mm |
| Type | : | Type A Single Strand Solid Stock Bore |
- Item Features 01=Without hardened teeth
