Martin 2060B19 MAR2060B19
Martin 2060B19 Conveyor Series Type B Double Pitch Solid Stock Bore Standard Roller Sprocket, 3/4 to 2-11/32 in Dia Bore, 4.94 in OD, #2060 Chain, 19 Teeth, Steel
- Manufacturer: Martin Sprocket & Gear
- Brand Name: Martin
- Part Number: MAR2060B19
- MPN: 2060B19
- UPC: 697950045337
- Min. Order Qty: 1
- Qty. Interval: 1
- Sign In for Pricing and Availability
- Sold As: 1/EA
-
Price:
Double pitch sprockets have rollers of the same diameters and widths as American Standard roller chains of one half the conveyor chain pitch. Engaged by every other tooth, double duty sprockets have two teeth per chain pitch. During each revolution only half the teeth function effectively. Sprockets with odd numbers of teeth will allow any given tooth to engage only on every other revolution, automatically increasing sprocket life. Double duty sprockets with even number of teeth may be manually advanced one tooth periodically to increase sprocket life.
Martin Standard Roller Sprocket, Type B Double Pitch Solid Stock Bore, Series: Conveyor Series, 3/4 to 2-11/32 in Bore, 4.94 in OD, #2060 Chain, 19 Teeth, 4.62 in Pitch Diameter, 3-1/2 in Diameter Hub, 1-1/4 in Length Through Bore, Steel
| Bore Diameter | : | 3/4 to 2-11/32 in |
| Chain Size | : | #2060 |
| Hub Diameter | : | 3-1/2 in |
| Length Through Bore | : | 1-1/4 in |
| Material | : | Steel |
| Number of Teeth | : | 19 |
| Outside Diameter | : | 4.94 in |
| Pitch Diameter | : | 4.62 in |
| Series | : | Conveyor Series |
| Type | : | Type B Double Pitch Solid Stock Bore |
- Without hardened teeth
