Martin 2040B16 MAR2040B16
  1. pin-int

Martin 2040B16 MAR2040B16

Martin 2040B16 Type B Single Strand Double Pitch Reboreable Roller Chain Sprocket, 5/8 to 1-9/32 in Dia Bore, 2.81 in OD, #2040 Chain, 16 Teeth, 1 in Pitch, Steel

  • Manufacturer: Martin Sprocket & Gear
  • Brand Name: Martin
  • Part Number: MAR2040B16
  • MPN: 2040B16
  • UPC: 697950044170
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • loading
  • Sign In for Pricing and Availability

Double pitch sprockets have rollers of the same diameters and widths as American standard roller chains of one half the conveyor chain pitch. Engaged by every other tooth, double duty sprockets have two teeth per chain pitch. During each revolution only half the teeth function effectively. Sprockets with odd numbers of teeth will allow any given tooth to engage only on every other revolution, automatically increasing sprocket life. Double duty sprockets with even number of teeth may be manually advanced one tooth periodically to increase sprocket life.

Martin Roller Chain Sprocket, Type B Single Strand Double Pitch Reboreable, 5/8 to 1-9/32 in Bore, 2.81 in OD, #2040 Chain, 16 Teeth, 1 in Pitch, 2.613 in Pitch Diameter, 1-7/8 in Diameter Hub, 7/8 in Length Through Bore, Steel

Bore Diameter      :      5/8 to 1-9/32 in
Chain Size      :      #2040
Hub Diameter      :      1-7/8 in
Length Through Bore      :      7/8 in
Material      :      Steel
Number of Teeth      :      16
Outside Diameter      :      2.81 in
Pitch Diameter      :      2.613 in
Pitch      :      1 in
Type      :      Type B Single Strand Double Pitch Reboreable
  • Manufactured of high carbon steel
  • Precise machining and processes ensure consistent finish and high quality
