Martin 14CHU19B5 MAR14CHU19B5

Martin 14CHU19B5 Conveyor Hanger U-Bolt, 19B Style, 14 in Dia Conveyor, 2-7/16 in Coupling

  • Manufacturer: Martin Sprocket & Gear
  • Brand Name: Martin
  • Part Number: MAR14CHU19B5
  • MPN: 14CHU19B5
  • UPC: 697950181509
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • loading
  • Sign In for Pricing and Availability

The No. 19B hanger is similar in construction to the No. 18B except they are mounted on top of the trough angles. Built-in ledges provide supports for the ends of the cover. They are streamlined in design and permit free passage of the material. Top half is furnished with bronze bearing. Bottom half can be supplied in oil impregnated wood, hard iron, or other special caps may be furnished on request.

Martin Conveyor Hanger U-Bolt, 19B Style, 14 in Conveyor Diameter, 2-7/16 in Coupling, 9/16 in Bolt, 19-1/4 in Top Frame Length, 3 in Top Frame Width, 1-1/2 in Top Frame Thickness, Steel

Bolt Size      :      9/16 in
Conveyor Diameter      :      14 in
Coupling Size      :      2-7/16 in
Material      :      Steel
Style      :      19B
Top Frame Length      :      19-1/4 in
Top Frame Thickness      :      1-1/2 in
Top Frame Width      :      3 in
  • Hanger U-bolts are used to hold the bearing in place on a style 19B hanger
  • Laser cut flat pieces to ensure consistent finish and high quality
