Martin 1060T-HUB MAR1060T-HUB
Martin Blue-Flex™ 1060T-HUB Reboreable Hub, 1060M Coupling, 3/4 to 2-1/8 in Dia Bore, 2.508 in L Through Bore, 3 in Dia Hub, Steel
- Manufacturer: Martin Sprocket & Gear
- Brand Name: Martin
- Part Number: MAR1060T-HUB
- Alt Part Number: 1060M-HUB
- MPN: 1060T-HUB
- UPC: 697950915890
- Min. Order Qty: 1
- Qty. Interval: 1
- Sign In for Pricing and Availability
- Sold As: 1/EA
-
Price:
Martin Blue-Flex Grid Couplings handle high torque levels and high RPM applications in a small package. Unlike other metallic couplings, Martin Blue-Flex Grid Couplings have the ability to reduce vibration and cushion shockloads to driven and driving power transmitting equipment components. Martin Blue-Flex Couplings are available in sizes 1020-1170 in vertical and horizontal configurations with a rough stock bore. Same day/next day rebores are available upon request.
Martin Blue-Flex™ Hub, Reboreable, 1060M Coupling, 3/4 to 2-1/8 in Bore, 3 in Diameter Hub, 33/16 x 3/32 in, 1/4 x 1/8 in, 5/16 x 5/32 in, 3/8 x 3/16 in, 1/2 x 1/4 in Keyway, 2.508 in Length Through Bore, Steel, Black Oxide
| Bore Diameter | : | 3/4 to 2-1/8 in |
| Coupling Size | : | 1060M |
| Finish | : | Black Oxide |
| Hub Diameter | : | 3 in |
| Keyway Size | : | 3/16 x 3/32 in, 1/4 x 1/8 in, 5/16 x 5/32 in, 3/8 x 3/16 in, 1/2 x 1/4 in |
| Length Through Bore | : | 2.508 in |
| Material | : | Steel |
| Type | : | Reboreable |
- The progressive contact between the curved profile of the hub teeth and the flexible grid makes it possible to absorb impact energy by spreading it out, reducing the magnitude of the peak load
- Hubs are black oxide to prevent rust while providing component interchangeability with industry competitors
