Martin 06BTB20H MAR06BTB20H
Martin 06BTB20H Type B Single Strand Solid Stock Bore Roller Chain Sprocket With Hardened Teeth, 25.4 mm Dia Bore, 66.44 mm OD, #06B-1 Chain, 20 Teeth, 9.53 mm Pitch, Steel
- Manufacturer: Martin Sprocket & Gear
- Brand Name: Martin
- Part Number: MAR06BTB20H
- MPN: 06BTB20H
- UPC: 697950408385
- Min. Order Qty: 1
- Qty. Interval: 1
- Sign In for Pricing and Availability
- Sold As: 1/EA
-
Price:
A metric taper bushed sprocket is a sprocket where a tapered bushing is bolted into the taper bore that is machined in the sprocket. When installed this bushing is compressed onto the shaft providing a tight grip. Taper bushed sprockets have a tapered bushing bolted into a taper bore with hex head set screws instead of bolts.
Martin Roller Chain Sprocket, Type B Single Strand Solid Stock Bore, 25.4 mm Bore, 66.44 mm OD, #06B-1 Chain, 20 Teeth, 9.53 mm Pitch, 60.89 mm Pitch Diameter, 49 mm Diameter Hub, 22.23 mm Length Through Bore, 1008 Taper Bushing, Steel
| Bore Diameter | : | 25.4 mm |
| Bushing Type | : | 1008 Taper |
| Chain Size | : | #06B-1 |
| Hub Diameter | : | 49 mm |
| Length Through Bore | : | 22.23 mm |
| Material | : | Steel |
| Number of Teeth | : | 20 |
| Outside Diameter | : | 66.44 mm |
| Pitch Diameter | : | 60.89 mm |
| Pitch | : | 9.53 mm |
| Type | : | Type B Single Strand Solid Stock Bore |
- Item Features 01=Manufactured of high carbon steel
- Item Features 02=Precise machining and processes ensure consistent finish and high quality
- Item Features 03=Bores are concentric to pitch line, minimizing run out
