Lovejoy® 68514456487 LOV68514456487
Lovejoy® 68514456487 Type AL Style 1 Jaw Coupling Hub With Keyway and Setscrew, AL070 Coupling, 12 mm Dia Bore, 19.05 mm L Through Bore, 34.54 mm Dia Hub, Aluminum
- Manufacturer: Lovejoy
- Brand Name: Lovejoy®
- Part Number: LOV68514456487
- MPN: 68514456487
- UPC: 685144564870
- Min. Order Qty: 1
- Qty. Interval: 1
- Sign In for Pricing and Availability
- Sold As: 1/PK
-
Price:
Lovejoy® Jaw Coupling Hub, Type AL Style 1, AL070 Coupling, 12 mm Bore, 34.54 mm Diameter Hub, 31.75 mm Hub Length, 4 mm W x 1.8 mm D Keyway, 14000 rpm Maximum, 19.05 mm Length Through Bore, 1/4-20 Screw, Aluminum, Silver
| Bore Diameter | : | 12 mm |
| Coupling Size | : | AL070 |
| Finish | : | Silver |
| Hub Diameter | : | 34.54 mm |
| Hub Length | : | 31.75 mm |
| Keyway Size | : | 4 mm W x 1.8 mm D |
| Length Through Bore | : | 19.05 mm |
| Material | : | Aluminum |
| Maximum Speed | : | 14000 rpm |
| Screw Size | : | 1/4-20 |
| Type | : | Type AL Style 1 |
- Interchangeable with all hub sizes standard for the L-line and AL-line products
- Finished bores passivated for additional rust protection
Specification Sheet
