Lovejoy® 68514424670 LOVL099/100SW
  1. pin-int

Lovejoy® 68514424670 LOVL099/100SW

Lovejoy® 68514424670 Type SW Snap Wrap Spider With Ring, SW099/100 Coupling, 3.08 in OD, 3600 rpm Max, Buna-N

  • Manufacturer: Lovejoy
  • Brand Name: Lovejoy®
  • Part Number: LOVL099/100SW
  • MPN: 68514424670
  • UPC: 685144246707
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • loading
  • Sign In for Pricing and Availability

Lovejoy® Spider, Type SW Snap Wrap, SW099/100 Coupling, 1.37 in ID, 3.08 in OD, 35.9 to 47.1 N-m Torque, 3600 rpm Maximum, For Use With: Type SW Jaw Coupling, -40 to 212 deg F, 80A Durometer, Buna-N, Black

Coupling Size      :      SW099/100
Durometer      :      80A
Finish      :      Black
Inside Diameter      :      1.37 in
Material      :      Buna-N
Maximum Speed      :      3600 rpm
Outside Diameter      :      3.08 in
Suitable For Use With      :      Type SW Jaw Coupling
Temperature Rating      :      -40 to 212 deg F
Torque Rating      :      35.9 to 47.1 N-m
Type      :      Type SW Snap Wrap
  • Nitrile Butadiene (Buna N) Rubber is a flexible elastomer material that is oil-resistant, resembles natural rubber in resilience and elasticity and operates effectively in temperature range of -40 to 212 deg F (-40 to 100 deg C)
  • Good resistance to oil
  • Standard elastomer (also applies to SXB cushions)
  • pdfCatalog https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Lovejoy_68514411133_Catalog.pdf
