Link-Belt® 10479847 REXFC115T
Link-Belt® 10479847 FC Series Fixed Flanged Cartridge Block Spherical Roller Bearing, 1-15/16 in Dia Bore, 3.8 in L Bolt Center-to-Center, 2.69 in Dia Bolt Circle, 4-Bolt Round Flange Mount, 6.38 in OAL/Dia
- Manufacturer: Regal Rexnord
- Brand Name: Link-Belt®
- Part Number: REXFC115T
- Alt Part Number: FC115T
- MPN: 10479847
- UPC: 782934929878
- Min. Order Qty: 1
- Qty. Interval: 1
- Sign In for Pricing and Availability
- Sold As: 1/EA
-
Price:
Link-Belt® Flanged Cartridge Block Spherical Roller Bearing, Fixed, Series: FC Series, 1-15/16 in Bore, 3.8 in Bolt Center-to-Center Length, 2.69 in Diameter Bolt Circle, 4-Bolt Round Flange Mounting, 6.38 in Overall Length/Diameter, 2.84 in Overall Depth, Single Set Screw Collar Locking Device, Cast Iron Bearing, 21000 lb Dynamic/24710 lb Static Load, 3060 rpm Maximum, -40 to 250 deg F, Powder Coated
| Bearing Material | : | Cast Iron |
| Bolt Center-to-Center Length | : | 3.8 in |
| Bolt Circle Diameter | : | 2.69 in |
| Bore Diameter | : | 1-15/16 in |
| Finish | : | Powder Coated |
| Flange Mounting Type | : | 4-Bolt Round |
| Load Capacity | : | 21000 lb Dynamic/24710 lb Static |
| Locking Device | : | Single Set Screw Collar |
| Maximum Speed | : | 3060 rpm |
| Overall Depth | : | 2.84 in |
| Overall Length/Diameter | : | 6.38 in |
| Series | : | FC Series |
| Temperature Rating | : | -40 to 250 deg F |
| Type | : | Fixed |
- Spherical roller bearing allows for +/- 2 deg of misalignment to accommodate variations between shaft and support structure as well as shaft deflection during operation
- Double contoured retainer pockets
- Factory set clearance and lubrication
- Extended inner ring, separable outer rings
- Triple lip seal
- Exxon Ronex™ MP grease
Instruction/Installation Manual
