Link-Belt® 10436397 LNKFB22423E

Link-Belt® 10436397 B22400 Fixed Flanged Spherical Roller Bearing, 1-7/16 in Dia Bore, 5 in Dia Bolt Circle, 3-Bolt Round/Bracket Flange Mount, 5-7/8 in OAL/Dia

  • Manufacturer: Regal Rexnord
  • Brand Name: Link-Belt®
  • Part Number: LNKFB22423E
  • Alt Part Number: FB22423E
  • MPN: 10436397
  • UPC: 662327026295
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • loading
  • Sign In for Pricing and Availability

Self-aligning double row spherical roller bearings are designed to distribute the load over the symmetrical rollers, assuring positive tracking and smooth operation. The large roller complement provides high capacity for radial or combined radial-thrust loads. Osculation clearance at the ends of the rollers compensates for shock loads and prevents destructive edge loading. These precision bearings with double contoured retainer pockets are designed to meet a broad range of application requirements.

Link-Belt® Flanged Spherical Roller Bearing, Fixed, Series: B22400, 1-7/16 in Bore, 5 in Diameter Bolt Circle, 3-Bolt Round/Bracket Flange Mounting, 5-7/8 in Overall Length/Diameter, 2-29/32 in Overall Depth, 6-1/4 in Overall Height, Single Set Screw Collar Locking Device, Cast Iron Bearing, 14600 lb Dynamic/20900 lb Static Load, 2750 rpm Maximum, 225 deg F, Powder Coated

Bearing Material      :      Cast Iron
Bolt Circle Diameter      :      5 in
Bore Diameter      :      1-7/16 in
Finish      :      Powder Coated
Flange Mounting Type      :      3-Bolt Round/Bracket
Load Capacity      :      14600 lb Dynamic/20900 lb Static
Locking Device      :      Single Set Screw Collar
Maximum Speed      :      2750 rpm
Overall Depth      :      2-29/32 in
Overall Height      :      6-1/4 in
Overall Length/Diameter      :      5-7/8 in
Series      :      B22400
Temperature Rating      :      225 deg F
Type      :      Fixed
  • Spherical roller bearing allows for +/- 2 deg of misalignment to accommodate variations between shaft and support structure as well as shaft deflection during operation
  • Double contoured retainer pockets
  • Type E spring loaded lip seals utilize a spring to provide uniform pressure for keeping the sealing lip in contact with the inner ring
  • 4 deg misalignment capabilities
  • Factory set clearance and lubrication
