Link-Belt® 10419470 LNKCSEB22563E
  1. pin-int

Link-Belt® 10419470 LNKCSEB22563E

Link-Belt® 10419470 B22500 Mounted Spherical Roller Bearing Cartridge Block, 3-15/16 in Dia Bore, 6.194 in OD, 6-1/8 in W, 96500 lb Dynamic/137000 lb Static Load

  • Manufacturer: Regal Rexnord
  • Brand Name: Link-Belt®
  • Part Number: LNKCSEB22563E
  • Alt Part Number: CSEB22563E
  • MPN: 10419470
  • UPC: 662327013370
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • loading
  • Sign In for Pricing and Availability

Link-Belt® Spherical Roller Bearing Cartridge Block, Mounted, Series: B22500, 3-15/16 in Bore Dia, 6.194 in Outside Dia, 6-1/8 in Width, 96500 lb Dynamic/137000 lb Static Load, 1100 rpm Maximum, 225 deg F, Uncoated

Bore Diameter      :      3-15/16 in
Finish      :      Uncoated
Load Capacity      :      96500 lb Dynamic/137000 lb Static
Maximum Speed      :      1100 rpm
Outside Diameter      :      6.194 in
Series      :      B22500
Temperature Rating      :      225 deg F
Type      :      Mounted
Width      :      6-1/8 in
  • Steel housing
  • Misalignment capabilities total of 4 deg
  • Factory set clearance and lubrication
  • Two hardened spring locking collars
  • Spring loaded heavy contact seal
  • Bearings are easy to mount, sealed, pre-lubricated and do not require bearing adjustment during mounting
