Link-Belt® 10415654 LNKPL3U224N
  1. pin-int

Link-Belt® 10415654 LNKPL3U224N

Link-Belt® 10415654 200 Standard-Duty Pillow Block Ball Bearing Unit, 1-1/2 in Dia Bore, 5-3/8 in L Bolt Center-to-Center, 1-15/16 in Base to Bore Centerline, 7-1/16 in OAL x 3-15/16 in OAH

  • Manufacturer: Regal Rexnord
  • Brand Name: Link-Belt®
  • Part Number: LNKPL3U224N
  • Alt Part Number: PL3U224N
  • MPN: 10415654
  • UPC: 662327118648
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • loading
  • Sign In for Pricing and Availability

200 series standard duty ball bearing units provide a versatility of application arrangements for carrying shafts with radial or combination radial and thrust loads. They are designed for general purpose industrial machinery, conveyors, chain and belt drives, fans and blowers, power transmission and many other applications.

Link-Belt® Pillow Block Ball Bearing Unit, Standard-Duty, Series: 200, 1-1/2 in Bore, 5-3/8 in Bolt Center-to-Center Length, 1-15/16 in Base to Bore Centerline, 7-1/16 in Overall Length, 1-29/32 in Overall Width, 3-15/16 in Overall Height, Two-Bolt Base Mounting, Round Bore, 1-7/8 in Base Width, Set Screw Locking Device, Single Lip Seal, Non-Expansion (Fixed) Expansion, 7330 lb Dynamic/4460 lb Static Load, 225 deg F, 6000 rpm Maximum, Cast Iron, Powder Coated

Base Width      :      1-7/8 in
Base to Bore Centerline      :      1-15/16 in
Bolt Center-to-Center Length      :      5-3/8 in
Bore Diameter      :      1-1/2 in
Bore Type      :      Round
Expansion Type      :      Non-Expansion (Fixed)
Finish      :      Powder Coated
Load Capacity      :      7330 lb Dynamic/4460 lb Static
Locking Device      :      Set Screw
Material      :      Cast Iron
Maximum Speed      :      6000 rpm
Mounting Type      :      Two-Bolt Base
Overall Height      :      3-15/16 in
Overall Length      :      7-1/16 in
Overall Width      :      1-29/32 in
Seal Type      :      Single Lip
Series      :      200
Temperature Rating      :      225 deg F
Type      :      Standard-Duty
  • Alignable precision deep groove ball bearing manufactured of quality alloy bearing steel provides high capacity and long life
  • Compact 1-piece housing provides excellent mounting support
  • Low backing height
  • Integral bearing seals
  • Wide inner ring for increased shaft stability
  • Relubricatable bearing
  • 208 size code
