Link-Belt® 10407264 LNKA23334S
Link-Belt® 10407264 A20000 Unmounted Spherical Roller Bearing, 3.3457 in Dia Bore, 5.9045 in OD, 1 Row, 1.109 in W, 29800 lb Dynamic/45300 lb Static Load
- Manufacturer: Regal Rexnord
- Brand Name: Link-Belt®
- Part Number: LNKA23334S
- Alt Part Number: A23334S
- MPN: 10407264
- UPC: 662327004767
- Min. Order Qty: 1
- Qty. Interval: 1
- Sign In for Pricing and Availability
- Sold As: 1/EA
-
Price:
Link-Belt® Spherical Roller Bearing, Unmounted, Series: A20000, 3.3457 in Bore Dia, 5.9045 in Outside Dia, 1 Row, 1.109 in W, Open Closure, 29800 lb Dynamic/45300 lb Static, Steel Cage, 2650 rpm Oil Maximum, Uncoated
| Bore Diameter | : | 3.3457 in |
| Cage Material | : | Steel |
| Closure Type | : | Open |
| Finish | : | Uncoated |
| Load Capacity | : | 29800 lb Dynamic/45300 lb Static |
| Maximum Speed | : | 2650 rpm Oil |
| Number of Rows | : | 1 |
| Outside Diameter | : | 5.9045 in |
| Series | : | A20000 |
| Type | : | Unmounted |
| Width | : | 1.109 in |
- Raceway curvatures
- Roller guidance is provided by double contoured coined steel retainer pockets
- Large rollers for extended bearing life
- Micro finished raceways assure smooth operation
- Adjustable, self-aligning
- Separable outer rings
- Direct shaft mounted
- A23334S bearing number
