Link-Belt® 10406016 LNKFB22655E

Self-aligning double row spherical roller bearings are designed to distribute the load over the symmetrical rollers, assuring positive tracking and smooth operation. The large roller complement provides high capacity for radial or combined radial-thrust loads. Osculation clearance at the ends of the rollers compensates for shock loads and prevents destructive edge loading. These precision bearings with double contoured retainer pockets are designed to meet a broad range of application requirements.

Link-Belt® Flanged Spherical Roller Bearing, Fixed, Series: B22600, 3-7/16 in Bore, 6-23/32 in Bolt Center-to-Center Length, 9-1/2 in Diameter Bolt Circle, 4-Bolt Square Flange Mounting, 8-7/16 in Overall Length/Diameter, 4-29/32 in Overall Depth, 11-7/16 in Overall Height, Adapter Mounted Locking Device, Cast Iron Bearing, 51000 lb Dynamic/90700 lb Static Load, 1250 rpm Maximum, 225 deg F, Powder Coated

• Spherical roller bearing allows for +/- 2 deg of misalignment to accommodate variations between shaft and support structure as well as shaft deflection during operation
• Double contoured retainer pockets
• Type E spring loaded lip seals utilize a spring to provide uniform pressure for keeping the sealing lip in contact with the inner ring
• 4 deg misalignment capabilities
• Factory set clearance and lubrication
• Enhanced life mounting style

• Instruction/Installation Manual https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Link_Belt_BY409302_Manual.pdf
