IPTCI Bearings UCP205-16L3 IPTUCP205-16L3
IPTCI Bearings UCP205-16L3 UCP Standard Duty Pillow Block, 1 in Dia Bore, 105 mm L Bolt Center-to-Center, 1.43 in Base to Bore Centerline, 140 mm OAL x 72 mm OAH
- Manufacturer: Solve Industrial Motion Group
- Brand Name: IPTCI Bearings
- Part Number: IPTUCP205-16L3
- Alt Part Number: 2101032464
- MPN: UCP205-16L3
- Min. Order Qty: 1
- Qty. Interval: 1
- Sign In for Pricing and Availability
- Sold As: 1/EA
-
Price:
IPTCI Bearings, UCP205-16L3, Pillow Block, Standard Duty, Series: UCP, 1 in Bore, 105 mm Bolt Center-to-Center Length, 1.43 in Base to Bore Centerline, 140 mm Overall Length, 38 mm Overall Width, 72 mm Overall Height, 38 mm Base Width, Set Screw Locking Device, Triple Lip Seal, 3010 lb Dynamic/1750 lb Static Load, 248 deg F, Cast Iron
| Base Width | : | 38 mm |
| Base to Bore Centerline | : | 1.43 in |
| Bolt Center-to-Center Length | : | 105 mm |
| Bore Diameter | : | 1 in |
| Load Capacity | : | 3010 lb Dynamic/1750 lb Static |
| Locking Device | : | Set Screw |
| Material | : | Cast Iron |
| Overall Height | : | 72 mm |
| Overall Length | : | 140 mm |
| Overall Width | : | 38 mm |
| Seal Type | : | Triple Lip Seal |
| Series | : | UCP |
| Temperature Rating | : | 248 deg F |
| Type | : | Standard Duty |
