IPTCI Bearings SUCSOF 207 22 IPTSUCSF207-22
IPTCI Bearings SUCSOF 207 22 Stand-Off Series Flange Block Bearing With SUC 207-22 Stainless Steel Bearing Insert and Type-B Seal, 1-3/8 in Dia Bore, 3-5/8 in L Bolt Center-to-Center, 4-Bolt Flange Mount, 4-19/32 in OAL/Dia
- Manufacturer: Solve Industrial Motion Group
- Brand Name: IPTCI Bearings
- Part Number: IPTSUCSF207-22
- MPN: SUCSOF 207 22
- Min. Order Qty: 1
- Qty. Interval: 1
- Sign In for Pricing and Availability
- Sold As: 1/EA
-
Price:
IPTCI Bearings introduces the new Stand-Off Series. These all-stainless mounted units are designed with extended mounting pads to reduce housing-to-mounting surface contact and create approximately 1/2 in of clearance underneath the bearing unit.
IPTCI Bearings Flange Block Bearing, Series: SUCSOF Stand-Off Series, 1-3/8 in Bore Dia, 3-5/8 in L Bolt Center-to-Center, 4-Bolt Flange Mounting, 4-19/32 in Overall Length/Diameter, 4-19/32 in Overall Height, Set Screw Locking Device, Stainless Steel Bearing, Silicone Rubber Seal
| Bearing Material | : | Stainless Steel |
| Bolt Center-to-Center Length | : | 3-5/8 in |
| Bore Diameter | : | 1-3/8 in |
| Flange Mounting Type | : | 4-Bolt |
| Locking Device | : | Set Screw |
| Overall Height | : | 4-19/32 in |
| Overall Length/Diameter | : | 4-19/32 in |
| Seal Material | : | Silicone Rubber |
| Series | : | SUCSOF Stand-Off Series |
Instruction/Installation Manual
