INA RAE30-XL-NPP-FA106 INARAE30XLNPPFA106
INA RAE30-XL-NPP-FA106 RAE..-NPP Radial Insert Ball Bearing, 30 mm Dia Bore, 62 mm OD, 1 Rows, 35.8 mm W, 20700 N Dynamic/11300 N Static/570 N Fatigue Load
- Manufacturer: Schaeffler Group
- Brand Name: INA
- Part Number: INARAE30XLNPPFA106
- Alt Part Number: RAE30-NPP-FA106
- MPN: RAE30-XL-NPP-FA106
- Min. Order Qty: 1
- Qty. Interval: 1
- Sign In for Pricing and Availability
- Sold As: 1/EA
-
Price:
INA Radial Insert Ball Bearing, Series: RAE..-NPP, 30 mm Bore, 62 mm OD, 1 Rows, 35.8 mm Width, Double Seal Closure, 20700 N Dynamic/11300 N Static/570 N Fatigue Load, Polyamide 66 Cage, -20 to 120 deg C, Uncoated
| Bore Diameter | : | 30 mm |
| Cage Material | : | Polyamide 66 |
| Closure Type | : | Double Seal |
| Finish | : | Uncoated |
| Load Capacity | : | 20700 N Dynamic/11300 N Static/570 N Fatigue |
| Number of Rows | : | 1 |
| Outside Diameter | : | 62 mm |
| Series | : | RAE..-NPP |
| Temperature Rating | : | -20 to 120 deg C |
| Width | : | 35.8 mm |
- Cylindrical outer ring
- Location by eccentric locking collar
- P seals on both sides
- Bearing subjected to special noise testing
Specification Sheet
