INA NK10/16-TV-XL INANK10/16
  1. pin-int

INA NK10/16-TV-XL INANK10/16

INA NK10/16-TV-XL Precision Needle Roller Bearing, 10 mm Dia Bore, 17 mm OD, 16 mm W, 7000 N Dynamic/7800 N Static/1310 N Fatigue Load

  • Manufacturer: Schaeffler Group
  • Brand Name: INA
  • Part Number: INANK10/16
  • MPN: NK10/16-TV-XL
  • Min. Order Qty: 1
  • Qty. Interval: 1
    • Sign In for Pricing and Availability

INA Precision Needle Roller Bearing, Series: NK Series, 10 mm Bore Dia, 17 mm Outside Dia, 16 mm Width, 7000 N Dynamic/7800 N Static/1310 N Fatigue, 29500 rpm Maximum

Bore Diameter      :      10 mm
Load Capacity      :      7000 N Dynamic/7800 N Static/1310 N Fatigue
Maximum Speed      :      29500 rpm
Outside Diameter      :      17 mm
Series      :      NK Series
Width      :      16 mm
  • Without inner ring
  • Ground raceways with ribs
  • Cage guided rollers
  • Through hardened machined and ground raceways with cage and roller complements
  • Retainer guides needles providing full length roller contact for maximum capacity, low friction and long life
  • Design series exist to match ISO, DIN, popular metric and inch dimension series
  • Location hole and groove in outer ring
  • pdfSpecification Sheet https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/INA_NK10_16_TV_L_Specification_Sheet.pdf
