INA LFR5201-10-2Z INALFR5201-10-2Z
INA LFR5201-10-2Z LFR..-2Z Yoke Track Roller With Profiled Outer Ring, 12 mm Dia Bore, 35 mm Dia x 15.9 mm W Roller, 8400 N Dynamic/5000 N Static/250 N Fatigue Load
- Manufacturer: Schaeffler Group
- Brand Name: INA
- Part Number: INALFR5201-10-2Z
- MPN: LFR5201-10-2Z
- Min. Order Qty: 1
- Qty. Interval: 1
- Sign In for Pricing and Availability
- Sold As: 1/EA
-
Price:
INA Track Roller, Yoke, Series: LFR..-2Z, 12 mm Bore, 35 mm Roller Diameter, 15.9 mm Roller Width, 15.9 mm Overall Width, 8400 N Dynamic/5000 N Static/250 N Fatigue Load, Double Seal Closure, Uncoated
| Bore Diameter | : | 12 mm |
| Closure Type | : | Double Seal |
| Finish | : | Uncoated |
| Load Capacity | : | 8400 N Dynamic/5000 N Static/250 N Fatigue |
| Overall Width | : | 15.9 mm |
| Roller Diameter | : | 35 mm |
| Roller Width | : | 15.9 mm |
| Series | : | LFR..-2Z |
| Type | : | Yoke |
- Locating bearing track rollers
- Double row
- Gap seal on both sides
Specification Sheet
