INA linear ball bearings of series KH are linear recirculation ball bearing units of very small radial section height. They consist of a drawn and hardened outer cup and a plastic cage. The outer cup, cage and balls form a closed linear bearing which is ready to assemble. These units are suitable for applications where long travel distances, low space requirements and predominantly maintenance free operation are required.
INA Linear Ball Bushing Bearing, Series: KH..-PP, 20 mm Shaft Dia, 28 mm Outside Dia, 28 mm Height, 30 mm Length, 28 mm W, Closed Closure, 1110 to 1170 N Dynamic/790 to 1010 N Static, Alloy Steel Bearing, Polyester Elastomer Seal, Linear Lube Lubrication, -30 to 80 deg C
| Bearing Material | : | Alloy Steel |
| Closure Type | : | Closed |
| Height | : | 28 mm |
| Length | : | 30 mm |
| Load Capacity | : | 1110 to 1170 N Dynamic/790 to 1010 N Static |
| Lubrication Type | : | Linear Lube |
| Outside Diameter | : | 28 mm |
| Seal Material | : | Polyester Elastomer |
| Series | : | KH..-PP |
| Shaft Diameter | : | 20 mm |
| Temperature Rating | : | -30 to 80 deg C |
| Width | : | 28 mm |
- Very small radial section height
- Axial location is not required
- Optimum sealing
- Lubricant is retained in the bearing
