INA linear ball bearings of series KB consist of a hardened and ground outer ring and a cage in which the balls are guided. The balls in the return zones are held in place by spring elements. This ensures that even heavily loaded or preloaded bearings have a uniform, low resistance to displacement.
INA Linear Ball Bushing Bearing, Series: KB Series, 25 mm Shaft Dia, 40 mm Outside Dia, 40 mm Height, 58 mm Length, 40 mm W, Closed Closure, 2800 to 2950/2220 to 2850 N, Alloy Steel Bearing, -30 to 80 deg C
| Bearing Material | : | Alloy Steel |
| Closure Type | : | Closed |
| Height | : | 40 mm |
| Length | : | 58 mm |
| Load Capacity | : | 2800 to 2950/2220 to 2850 N |
| Outside Diameter | : | 40 mm |
| Series | : | KB Series |
| Shaft Diameter | : | 25 mm |
| Temperature Rating | : | -30 to 80 deg C |
| Width | : | 40 mm |
- The special recirculation design provides a uniform, low resistance to displacement with extremely smooth running even in highly loaded and preloaded linear ball bearings
