INA BK1414-RS INABK1414-RS
  1. pin-int

INA BK1414-RS INABK1414-RS

INA BK1414-RS BK..-RS Drawn Cup Needle Roller Bearing With Closed End, 14 mm Dia Bore, 20 mm OD, 1 Row, 14 mm W, 7100 N Dynamic/8500 N Static/1010 N Fatigue Load

  • Manufacturer: Schaeffler Group
  • Brand Name: INA
  • Part Number: INABK1414-RS
  • MPN: BK1414-RS
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • loading
  • Sign In for Pricing and Availability

INA Drawn Cup Needle Roller Bearing, Series: BK..-RS, 14 mm Bore Dia, 20 mm Outside Dia, 1 Row, 14 mm W, Single Sealed Closure, 7100 N Dynamic/8500 N Static/1010 N Fatigue, Steel Cage, 10500 rpm Maximum, -30 to 100 deg C

Bore Diameter      :      14 mm
Cage Material      :      Steel
Closure Type      :      Single Sealed
Load Capacity      :      7100 N Dynamic/8500 N Static/1010 N Fatigue
Maximum Speed      :      10500 rpm
Number of Rows      :      1
Outside Diameter      :      20 mm
Series      :      BK..-RS
Temperature Rating      :      -30 to 100 deg C
Width      :      14 mm
  • Lip seal on one side
  • Deep drawn shell design for maximum capacity in the minimum radial space
  • Cage guided needle rollers for low friction, whole roller loading and high speeds
  • With one end closed for shaft end locations to improve sealing
  • Easily mounted without snap rings or shoulders
