IKO RNA4914UU IKORNA4914UU
IKO RNA4914UU Metric Series Caged Machined Needle Roller Bearing With Oil Hole, 80 mm Dia Bore, 100 mm OD, 1 Row, 30 mm W, 76900 N Dynamic/143000 N Static Load
- Manufacturer: IKO International
- Brand Name: IKO
- Part Number: IKORNA4914UU
- MPN: RNA4914UU
- Min. Order Qty: 1
- Qty. Interval: 1
- Sign In for Pricing and Availability
- Sold As: 1/EA
-
Price:
IKO manufactures a wide range of radial Needle Roller Bearings to meet the needs of different applications and machine profiles. These include shell type bearings, needle roller cages for both general use and within engine connecting rods and machined type Needle Roller Bearings. Machined type Needle Roller Bearings feature low sectional height and large load ratings. A highly rigid outer ring makes these bearings ideal for light alloy housings as well.
IKO Needle Roller Bearing, Caged Machined, Series: RNA49 Metric Series, 80 mm Bore, 100 mm OD, 1 Row, 30 mm Width, Double Seal Closure, 76900 N Dynamic/143000 N Static Load, High Carbon Steel Bearing, Synthetic Rubber Seal, 2500 rpm Maximum
| Bearing Material | : | High Carbon Steel |
| Bore Diameter | : | 80 mm |
| Closure Type | : | Double Seal |
| Load Capacity | : | 76900 N Dynamic/143000 N Static |
| Maximum Speed | : | 2500 rpm |
| Number of Rows | : | 1 |
| Outside Diameter | : | 100 mm |
| Seal Material | : | Synthetic Rubber |
| Series | : | RNA49 Metric Series |
| Type | : | Caged Machined |
| Width | : | 30 mm |
- Item Features 01=Suitable for a wide range of conditions including heavy loads requiring either high-speed or low-speed rotation
- Item Features 02=Design choices include bearings with or without inner rings, ringless style uses a shaft as the raceway for a streamlined, compact footprint
- Item Features 03=With seals on both side
- Item Features 04=Without inner ring
- Item Features 05=Pre-packed grease
