IDC Select® IDC 80-2R IDC80-2R-10
  1. pin-int

IDC Select® IDC 80-2R IDC80-2R-10

IDC Select® IDC 80-2R Riveted Roller Chain, 10 ft OAL, 1 in Pitch, 0.63 in Dia x 0.62 in W Roller, Carbon Steel

  • Manufacturer: IDC Select
  • Brand Name: IDC Select®
  • Part Number: IDC80-2R-10
  • MPN: IDC 80-2R
  • UPC: 887412056760
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • loading
  • Sign In for Pricing and Availability

ANSI standard roller chains represent the most common roller chain sold in the market today. IDC Select® roller chain is manufactured in accordance with American National Standards Institute (ANSI) standard roller chains B29.1 standards. IDC Select® roller chain is designed and built to provide maximum strength and wear life. Solid bushings, solid rollers, wide waist link plates and appropriate press fits are just a few of the reasons it outperforms the competition.

IDC Select® Roller Chain, Riveted, 1 in Pitch, 0.31 in Pin Diameter, 2.53 in Pin Length, 0.63 in Roller Diameter, 0.62 in Roller Width, 0.94 in Plate Height, 0.13 in Plate Thickness, 2 Strands, 25773 lb Ultimate/32231.85 lb Average Tensile Strength, 10 ft Overall Length, Carbon Steel

Material      :      Carbon Steel
Number of Strands      :      2
Overall Length      :      10 ft
Pin Diameter      :      0.31 in
Pin Length      :      2.53 in
Pitch      :      1 in
Plate Height      :      0.94 in
Plate Thickness      :      0.13 in
Roller Diameter      :      0.63 in
Roller Width      :      0.62 in
Tensile Strength      :      25773 lb Ultimate/32231.85 lb Average
Type      :      Riveted
  • pdfCatalog https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/IDC_SELECT_IDC_81X_Catalog.pdf
  • pdfTechnical Bulletin https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/IDC_SELECT_IDC_81X_Technical_Bulletin.pdf
