IDC Select® IDC 60BB13H-5/8 IDC60BB13H5/8
IDC Select® IDC 60BB13H-5/8 A-Style Ball Bearing Idler Sprocket, 5/8 in Dia Bore, 60 Chain, 13 Teeth, Steel
- Manufacturer: IDC Select
- Brand Name: IDC Select®
- Part Number: IDC60BB13H5/8
- MPN: IDC 60BB13H-5/8
- Min. Order Qty: 1
- Qty. Interval: 1
- Sign In for Pricing and Availability
- Sold As: 1/EA
-
Price:
IDC Select® idler sprockets are available with precision ground ball bearings, needle bearings, and bronze bushed designs. Idler sprockets are available for #25 through #80 chain sizes. They include hardened teeth to resist wear and damage to the chain.
IDC Select® Ball Bearing Idler Sprocket, A-Style, 5/8 in Bore Dia, 60 Chain, 13 Teeth, 11/16 in Length Through Bore, Steel
| Bore Diameter | : | 5/8 in |
| Chain Size | : | 60 |
| Length Through Bore | : | 11/16 in |
| Material | : | Steel |
| Number of Teeth | : | 13 |
| Type | : | A-Style |
- Adjust chain tension in a situation where the driving or driven shaft is not adjustable
- Compensate for chain slack developed through normal chain wear
- Prevent unstable movement in chain slack when transmitting uneven load
- Provide greater chain grip around a small sprocket
- Direct chain around an obstruction
- Reverse direction of rotation of a sprocket in contact with the outside of the chain drive
- Precision ground prelubricated sealed bearings
- Compatible with a wide array of mounts and idler shafts
- Hardened sprocket teeth
