IDC Select® IDC 140-1R IDC140R-10
IDC Select® IDC 140-1R Riveted Roller Chain, 10 ft OAL, 1-3/4 in Pitch, 1 in Dia x 0.99 in W Roller, Carbon Steel
- Manufacturer: IDC Select
- Brand Name: IDC Select®
- Part Number: IDC140R-10
- MPN: IDC 140-1R
- UPC: 887412056876
- Min. Order Qty: 1
- Qty. Interval: 1
- Sign In for Pricing and Availability
- Sold As: 10/ft
-
Price:
ANSI standard roller chains represent the most common roller chain sold in the market today. IDC Select® roller chain is manufactured in accordance with American National Standards Institute (ANSI) standard roller chains B29.1 standards. IDC Select® roller chain is designed and built to provide maximum strength and wear life. Solid bushings, solid rollers, wide waist link plates and appropriate press fits are just a few of the reasons it outperforms the competition.
IDC Select® Roller Chain, Riveted, 1-3/4 in Pitch, 1/2 in Pin Diameter, 2.32 in Pin Length, 1 in Roller Diameter, 0.99 in Roller Width, 1.61 in Plate Height, 0.22 in Plate Thickness, 1 Strands, 39182 lb Ultimate/48188.66 lb Average Tensile Strength, 10 ft Overall Length, Carbon Steel
| Material | : | Carbon Steel |
| Number of Strands | : | 1 |
| Overall Length | : | 10 ft |
| Pin Diameter | : | 1/2 in |
| Pin Length | : | 2.32 in |
| Pitch | : | 1-3/4 in |
| Plate Height | : | 1.61 in |
| Plate Thickness | : | 0.22 in |
| Roller Diameter | : | 1 in |
| Roller Width | : | 0.99 in |
| Tensile Strength | : | 39182 lb Ultimate/48188.66 lb Average |
| Type | : | Riveted |
