IDC Select® IDC 10/5V3150M IDC10/5V3150M
IDC Select® IDC 10/5V3150M Heavy Duty Type A-3 Arm/Spoke Sheave, QD® Bore, 31-1/2 in OD, 10 Grooves, 31.4 in Dia Pitch, 7-3/16 in W Face
- Manufacturer: IDC Select
- Brand Name: IDC Select®
- Part Number: IDC10/5V3150M
- MPN: IDC 10/5V3150M
- UPC: 887412003276
- Min. Order Qty: 1
- Qty. Interval: 1
- Sign In for Pricing and Availability
- Sold As: 1/EA
-
Price:
IDC Select® classical A/B combination, C and D sheaves, and narrow 3V, 5V, and 8V sheaves are available in QD® bushing designs. They are precision machined from 30 gray cast iron, statically balanced, painted with a baked enamel finish and individually packaged.
IDC Select® Sheave, Heavy Duty Type A-3 Arm/Spoke, QD® Bore, 31-1/2 in OD, 31.4 in Pitch Diameter, 10 Grooves, 7-3/16 in Face Width, M Bushing, For Use With: 5V-Cross Section V-Belts, Cast Iron, Baked Enamel
| Bore Type | : | QD® |
| Bushing Type | : | M |
| Face Width | : | 7-3/16 in |
| Finish | : | Baked Enamel |
| Material | : | Cast Iron |
| Number of Grooves | : | 10 |
| Outside Diameter | : | 31-1/2 in |
| Pitch Diameter | : | 31.4 in |
| Suitable For Use With | : | 5V-Cross Section V-Belts |
| Type | : | Heavy Duty Type A-3 Arm/Spoke |
- Precision machined from gray cast iron
- Statically balanced
- Cast iron sheaves should not exceed 6500 fpm rim speed
- Special or dynamic balancing should be considered when speeds exceed 5000 fpm
- Accepts QD® style bushings
- M bushings use standard mounting only on this sheave
