HKK Chain RH200C1A HKK200HC-10

HKK Chain RH200C1A Heavy Series Cottered Roller Chain, 10 ft OAL, 2-1/2 in Pitch, 1.562 in Dia x 1-1/2 in W Roller, Alloy Steel

  • Manufacturer: HKK Chain Corporation
  • Brand Name: HKK Chain
  • Part Number: HKK200HC-10
  • MPN: RH200C1A
  • Min. Order Qty: 1
  • Qty. Interval: 1
    • Sign In for Pricing and Availability

HKK Chain Heavy Series roller chains have increased link plate thickness to provide higher fatigue strength and greater shock load capacity. HKK Chain Superior Capacity Plus® is a patented process which increases the fatigue strength even further. This increased strength, combined with our standard solid bushings and solid rollers make HKK Chain one of the highest quality, longest lasting chains available. Heavy Series link plate thickness is that of the next larger size chain. The letter "H" following the chain size signifies the chain is of the Heavy Series.

HKK Chain Roller Chain, Cottered, Series: Heavy Series, 2-1/2 in Pitch, 0.781 in Pin Dia, 1.562 in Roller Dia, 1-1/2 in Roller Width, 2.354 in Plate Height, 3/8 in Plate Thickness, 1 Strand, 10 ft Overall Length, Alloy Steel

Material      :      Alloy Steel
Number of Strands      :      1
Overall Length      :      10 ft
Pin Diameter      :      0.781 in
Pitch      :      2-1/2 in
Plate Height      :      2.354 in
Plate Thickness      :      3/8 in
Roller Diameter      :      1.562 in
Roller Width      :      1-1/2 in
Series      :      Heavy Series
Type      :      Cottered
  • One HKK Chain RH200CCL1 1-pin full strength cottered connecting link is supplied with each 10 ft of chain
  • RH200CHL1 offset link (half link), RH200-RL roller link (inner link) sold separately
  • Chain size 200H
  • pdfSpecification Sheet https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/HKK_Chain_100HC10_Specification_Sheet.pdf
