Heritage™ H1629Z3 ITW5350
Heritage™ H1629Z3 65 deg H1629Z3, 1/4-18 PTF Thread, 0.97 in OAL, Clear Trivalent Zinc Plated, Steel, 0.34 in L Shank
- Manufacturer: G. L. Huyett
- Brand Name: Heritage™
- Part Number: ITW5350
- MPN: H1629Z3
- Min. Order Qty: 1
- Qty. Interval: 1
- Sign In for Pricing and Availability
- Sold As: 1/EA
-
Price:
1/4-18 PTF fittings, which have 18 threads per inch, are used in large bearings on heavy machinery such as mining equipment and trucks. They are well suited for cold weather environments and for use with heavy lubricants.
Heritage™ Zerk Grease Fitting, 65 deg, 1/4-18 PTF Thread, 0.97 in Overall Length, 0.34 in Shank Length, 9/16 in Hex, Clear Trivalent Zinc Plated, Steel
California residents see Prop 65 WARNINGS
| Finish | : | Clear Trivalent Zinc Plated |
| Hex Size | : | 9/16 in |
| Material | : | Steel |
| Overall Length | : | 0.97 in |
| Shank Length | : | 0.34 in |
| Thread Size | : | 1/4-18 PTF |
| Type | : | 65 deg |
- Standard shank
- Special extra short thread
Specification Sheet
