Heritage™ H13154Z3 GLHH13154Z3
Heritage™ H13154Z3 Straight Bulk Head Tubing Connector, 1/8-27 Male NPSM (1/4-28 Female UNF) x 1/8-27 Female NPTF Thread, 0.88 in OAL, Clear Trivalent Zinc Plated, Steel, 0.38 in L Shank
- Manufacturer: G. L. Huyett
- Brand Name: Heritage™
- Part Number: GLHH13154Z3
- MPN: H13154Z3
- Min. Order Qty: 1
- Qty. Interval: 1
- Sign In for Pricing and Availability
- Sold As: 1/PK
-
Price:
Bulkhead connectors allow for the passage of a lubrication line through a bulkhead or other obstructions. A grease fitting may be installed to allow a remote access point, or an additional tubing connector may be added to continue the line.
Heritage™ Bulk Head Tubing Connector, Straight, 1/8-27 Male NPSM (1/4-28 Female UNF) x 1/8-27 Female NPTF Thread, 0.88 in Overall Length, 0.38 in Shank Length, Clear Trivalent Zinc Plated, Steel
California residents see Prop 65 WARNINGS
| Finish | : | Clear Trivalent Zinc Plated |
| Material | : | Steel |
| Overall Length | : | 0.88 in |
| Shank Length | : | 0.38 in |
| Thread Size | : | 1/8-27 Male NPSM (1/4-28 Female UNF) x 1/8-27 Female NPTF |
| Type | : | Straight |
- NPSM x FNPT Parallel x Taper thread
Specification Sheet
