Gates® C78 GATC78

Gates® Hi-Power® II C78 Banded Classical Heavy Duty V-Belt, C Section, 7/8 in W Top, 82 in L Outside, 17/32 in THK, EPDM

  • Manufacturer: Gates Corp
  • Brand Name: Gates®
  • Part Number: GATC78
  • MPN: C78
  • UPC: 072053210477
  • Min. Order Qty: 1
  • Qty. Interval: 1
    • Sign In for Pricing and Availability

The wrapped classical section Hi-Power™ V-belt has a long reputation for reliability on agricultural and industrial applications. The arched top of the Hi-Power belt provides superior strength to prevent "dishing" and distortion of the tensile section. The cords are properly aligned, each of them carrying its full share of the load.

Gates® Hi-Power® II V-Belt, Banded Classical Heavy Duty, Series: 9004, C Section, 7/8 in Top Width, 82 in Outside Length, 17/32 in Thickness, 1 Rib, 7.958 in Diameter Minimum Pulley, EPDM, Flex-Bonded Polyester Reinforced

Material      :      EPDM
Minimum Pulley Diameter      :      7.958 in
Number of Ribs      :      1
Outside Length      :      82 in
Reinforced Material      :      Flex-Bonded Polyester
Section Size      :      C
Series      :      9004
Thickness      :      17/32 in
Top Width      :      7/8 in
Type      :      Banded Classical Heavy Duty
  • Flex-bonded cords are strongly bonded to the body of the belt resulting in equal load distribution and the absorption of bending stress without cord deterioration
  • The Flex-Weave® cover is constructed for longer cover life, providing extended protection to the core of the belt from oil, dirt and heat
  • Gates® curves provide proper cord support and full contact with the sheave groove for uniform loading, uniform wear and increased belt life
  • Featuring a composite, multi-purpose construction, these belts resist oil and heat, ozone, sunlight, weather and aging
