Part Number: HOI-168, Weight (lbs.): 0.0116, RoHS Compliant: Yes, HTS Number: 7318240000, Inch or Metric: Inch, Finish: Phosphate, Material: Carbon Spring Steel, Type: internal, Hardness: HRC 47-52, Image: HOI-168.png, Country of Origin: USA, Groove Diameter: 1.792 in, Thickness: .062 in, Style: Stamped, Groove Width: .056 in, Allowable Corner Chamfers: .057 in, Allowable Corner Radii: .091 in, in Groove: 1.420 in, Edge Margin: .156 in, Free Diameter: 1.823 in, Groove Depth: .043 in, Groove Diameter to Shaft Concentricity: .005 in, Maximum Thrust Load: 2900 Pound-Force, Manufacturer Part Number: HOI-168ST PA, Free Diameter Tolerance: -1.53846153846154, Groove Diameter Tolerance: ±.005, Thickness Tolerance: ±.002, Hole Diameter: .076 in, Maximum Section: .166 in, Minimum Section: .079 in, Maximum Section Tolerance: ±.007, Hole Diameter Tolerance: -7.5, Minimum Section Tolerance: ±.007, Housing Diameter: 1.688 in, Military Specification: No, Gap Width Minimum: .405 in, in Housing: 1.320 in, Housing Diameter Fraction: 1-11/16 in
| Finish | : | Phosphate |
| Housing Diameter | : | 1.688 in |
| Material | : | Carbon Spring Steel |
| Thickness | : | .062 in |
| Type | : | internal |
