FYH® Pillow Block Unit, Series: UCP, 1 in Bore, 4-1/8 in Bolt Center-to-Center Length, Cylindrical Bore, Set Screw Locking Device, 3150 lbf Dynamic/1766 lbf Static Load, Cast Iron
| Bolt Center-to-Center Length | : | 4-1/8 in |
| Bore Diameter | : | 1 in |
| Bore Type | : | Cylindrical |
| Load Capacity | : | 3150 lbf Dynamic/1766 lbf Static |
| Locking Device | : | Set Screw |
| Material | : | Cast Iron |
| Series | : | UCP |
- P205 housing
- UC205-16 bearing
- Pillow block unit with a rigid cast iron housing and two specially designed set screws in the inner ring spaced at 120 deg for maximum holding power and reliability for a wide variety of applications and operating conditions
- 3/8 in bolt
- 5-1/2 in OAW
- 2-3/4 in OAH
- Basic Load Rating: 13.9 factor
- 1-1/2 in base depth
- 1-7/16 in center to base
- 1/4-28 UNF set screw size
- A-1/4-28 UNF grease fitting size
