FALK® 0725603 FAL0725603
  1. pin-int

FALK® 0725603 FAL0725603

FALK® 0725603 T20 Close Coupled Grid Coupling, 9 in Dia Bore, 21 in Dia Outside, 8.50 in OAL, 495000 in-lb Torque Rating, 1750 rpm Max

  • Manufacturer: Regal Rexnord
  • Brand Name: FALK®
  • Part Number: FAL0725603
  • MPN: 0725603
  • UPC: 782934011566
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Sign In for Pricing and Availability

FALK®, 0725603, Grid Coupling, Close Coupled, Series: T20, 9 in Bore, 21 in OD, 8.50 in Overall Length, 7.80 in Length Through Bore, 495000 in-lb Torque, 1750 rpm Maximum, 18 in H x 21 in W x 15.85 in L Dimensions

Bore Diameter      :      9 in
Dimensions      :      18 in H x 21 in W x 15.85 in L
Length Through Bore      :      7.80 in
Maximum Speed      :      1750 rpm
Outside Diameter      :      21 in
Overall Length      :      8.50 in
Series      :      T20
Torque Rating      :      495000 in-lb
Type      :      Close Coupled
