FAG QJ212-XL-TVP FAGQJ212TVP
FAG QJ212-XL-TVP 4-Point Angular Contact Ball Bearing, 60 mm Dia Bore, 110 mm OD, 1 Row, 22 mm W, 35 deg, 98000 N Load
- Manufacturer: Schaeffler Group
- Brand Name: FAG
- Part Number: FAGQJ212TVP
- MPN: QJ212-XL-TVP
- Min. Order Qty: 1
- Qty. Interval: 1
- Sign In for Pricing and Availability
- Sold As: 1/EA
-
Price:
Single-row angular contact ball bearings are self-retaining units with solid inner and outer rings and ball and cage assemblies with polyamide, sheet metal or brass cages. The raceways of the inner and outer rings are offset from each other along the bearing axis. The bearings are available in open and sealed designs. Their angular adjustment facility is very limited.
FAG Angular Contact Ball Bearing, 4-Point, Series: QJ2, 60 mm Bore, 110 mm OD, 1 Rows, 22 mm Width, 35 deg Contact Angle, Open Closure, 98000 N Load, Polyamide Cage, 7400 rpm Maximum, -30 to 120 deg C
| Bore Diameter | : | 60 mm |
| Cage Material | : | Polyamide |
| Closure Type | : | Open |
| Contact Angle | : | 35 deg |
| Load Capacity | : | 98000 N |
| Maximum Speed | : | 7400 rpm |
| Number of Rows | : | 1 |
| Outside Diameter | : | 110 mm |
| Series | : | QJ2 |
| Temperature Rating | : | -30 to 120 deg C |
| Type | : | 4-Point |
| Width | : | 22 mm |
- Four point contact bearings are particularly suitable where predominantly axial loads must be supported
- The axial design envelope is not sufficient for double row radial angular contact ball bearings
- Radial forces must be supported by a separate radial bearing
- Axial forces occur in both directions and a close axial guidance is required in conjunction with a small bearing width
- X-life design
- Standard window cage made from glass fiber reinforced polyamide PA66
- 98000 N dynamic/93000 N static
