FAG N211-E-XL-TVP2 FAGN211EXLTVP2
FAG N211-E-XL-TVP2 N2..-E Separable Outer Ring Cylindrical Roller Bearing With Cage, 55 mm Dia Bore, 100 mm OD, 1 Row, 21 mm W, 99000 N Dynamic/95000 N Static/16100 N Fatigue Load
- Manufacturer: Schaeffler Group
- Brand Name: FAG
- Part Number: FAGN211EXLTVP2
- Alt Part Number: N211-E-TVP2
- MPN: N211-E-XL-TVP2
- Min. Order Qty: 1
- Qty. Interval: 1
- Sign In for Pricing and Availability
- Sold As: 1/PK
-
Price:
FAG Cylindrical Roller Bearing, Separable Outer Ring, Series: N2..-E, 55 mm Bore Dia, 100 mm Outside Dia, 1 Row, 21 mm W, Open Closure, 99000 N Dynamic/95000 N Static/16100 N Fatigue, Polyamide 66 Cage, 16000 rpm Grease/19000 rpm Oil Maximum, -30 to 120 deg C, Uncoated
| Bore Diameter | : | 55 mm |
| Cage Material | : | Polyamide 66 |
| Closure Type | : | Open |
| Finish | : | Uncoated |
| Load Capacity | : | 99000 N Dynamic/95000 N Static/16100 N Fatigue |
| Maximum Speed | : | 16000 rpm Grease/19000 rpm Oil |
| Number of Rows | : | 1 |
| Outside Diameter | : | 100 mm |
| Series | : | N2..-E |
| Temperature Rating | : | -30 to 120 deg C |
| Type | : | Separable Outer Ring |
| Width | : | 21 mm |
- Non-locating bearing
Specification Sheet
